The Dell PowerEdge T320 is a 5U, 1-socket, rackable tower server. For additional system views and

features, see the

Dell PowerEdge T320 Systems Owner’s Manual

on Support.Dell.com/Manuals.

Table 4 lists the possible chassis configurations available for the T320.

Number of

drive bays

Drive types

Controller

Front

control

panel

Power supply

Rack

option

4 cabled

drive bays

3.5” SATA and

SAS HHD

PERC S110, H310, H710, H710P

LED

Cabled 350W

8 hot-plug

drive bays

3.5” SATA and

SAS HHD

2.5” SAS SSD

PERC S110, H310, H710, H710P

LCD

Cabled 350W

or hot-plug

495W, 750W

Yes

16 hot-plug

drive bays

2.5” SATA and

SAS SSD/HHD

PERC H310, H710, H710P

LCD

Hot-plug

495W, 750W

Yes

Figure 1 shows the features on the front of the T320 16-drive bay chassis with the front control

panel, USB connectors, and many other components and features described in this guide.

Figure 2 shows the optional lockable bezel on the front of the T320 chassis.
